Multi-tiered system of leveller units
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 17, 1995
Issued Date -
N/A
app pub date -
Jan 27, 1994
filing date -
Sep 18, 1992
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A multi-tiered system of leveller units for the levelling of recreational vehicles. The leveller units each comprise a planar body, with upper and lower surfaces circumscribed by edges. The body of each unit bears a plurality of pins upwardly extending from spaced locations in the upper surface and has a plurality of pin-engaging pockets formed in the lower surface to matably receive corresponding pins of other similar units. The pins are of slightly smaller size than the corresponding pockets so that when the pins of one unit are associated with the pockets of another, there is provided a loose engagement therebetween. The body may be formed of a discontinuous webbing providing light-weight strength and support to the units to support the large loads placed thereupon.
First Claim
Other Claims data not available
