Method for high-frequency drying of combustible goods and, with fire suppression
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 26, 1991
Issued Date -
N/A
app pub date -
Nov 24, 1989
filing date -
Mar 22, 1988
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
In the regions of a drying zone within a tunnel (2) exposed to fire danger a sample of the air streams is drawn off via an intake pipe (11) disposed transversely to the longitudinal extent of the tunnel. The sample is supplied to a measuring device which contains two regeneratable filters which are alternatingly acted upon by the sample via switch-over valves. The measuring device contains a sensor acted upon by the cleansed gas which sensor reacts to CO and is connected to an alarm system and or an extinguisher device. From the extinguisher device an extinguisher agent line (16) leads to an extinguisher pipe (14) which is likewise in the direction of flow of the air steam guided through the tunnel (2) arranged transversely to the longitudinal extent of the tunnel (2) and provided with extinguisher agent exit nozzles.
First Claim
Other Claims data not available
