US Patent No: 8018030

Semiconductor chip with seal ring and sacrificial corner pattern

---

Abstract

---

A semiconductor device according to the invention is a semiconductor device which includes a low dielectric constant film of which the relative dielectric constant is less than 3.5, is provided with one or more seal rings that are moisture blocking walls in closed loop form in a plan view, and where at least one of the seal rings includes a seal ring protrusion portion in inward protruding form in the vicinity of a chip corner.

---



---
