Spring clip cable support assemblies
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 27, 1988
Issued Date -
N/A
app pub date -
Apr 1, 1987
filing date -
Apr 1, 1987
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A spring clip cable support assembly for use with a cable comprising an outer conduit and an inner flexible cable extending through the conduit comprising a body having an opening therethrough and having a radial flange intermediate its ends, a spring clip pressed about a portion of the body and a resilient tubular seal member within the body. The spring clip has one end engaging the flange of the body and includes a first set of axially extending spring fingers having free ends extending radially outwardly and a second set of resilient spring fingers having free ends extending radially inwardly into the recess in the body. A portion of the body is crimped on a conduit and then the body and spring assembly are inserted through an opening in a wall or bracket with the wall extending the radial flange on the body. As the assembly is inserted into the opening, the first set of spring fingers are compressed radially inwardly and then spring outwardly locking the assembly and conduit in place and the second set of fingers engage the groove in the body.
First Claim
Other Claims data not available
