Large force multi-axis manipulating arm unit, especially for use as an industrial robot
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 15, 1987
Grant Date -
N/A
app pub date -
Apr 9, 1984
filing date -
Apr 9, 1983
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A freely programmable multi-axis articulated manipulating arm unit having arm elements disposed along different longitudinal axes especially for use as an industrial robot is provided with a drive system and a brake system for each of individual rotational or translational axes; the drive systems belonging to the rotational or translational axes of the manipulating arm unit are each provided with a hydraulically actuated locking brake which functions in a play-free manner, when in the operating braking state. Each of these brakes fixes adjacent arm-elements with respect to each other. Said adjacent arm elements are able to move about the rotational axes relative to each other when the said brakes are not operative. The arm elements are fixed directly in every position, that is, without the use of intermediate elements.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 33 Citation Count
- B25J Class
- 0 % this patent is cited more than
- 38 Age
