US Patent Application No: 2018/0024,400

ARRAY SUBSTRATE, MANUFACTURING METHOD THEREOF, REPAIRING METHOD THEREOF, DISPLAY PANEL AND DISPLAY DEVICE

---

Abstract

---

The present disclosure provides an array substrate, a manufacturing method thereof, a repairing method thereof, a display panel and a display device. The array substrate includes a base substrate, and a pixel electrode and a common electrode superimposed one on another on the base substrate. An electrically conductive layer is arranged at a region where the pixel electrode and the common electrode overlap each other. The electrically conductive layer is at least insulated from one of the pixel electrode and the common electrode.

---



---
