SENSING FOR AUTOMATED BIOLOGICAL CELL INJECTION
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
May 11, 2023
app pub date -
Nov 16, 2022
filing date -
Oct 31, 2016
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A method of controlling a needle actuator to interact with a cell is provided, the method comprising: providing an actuator comprising a tower, a stage and a needle, wherein the needle is mounted on the stage; applying an electrostatic potential between the tower and the stage to retract the needle; moving the actuator towards the cell; reducing the potential so as to allow the stage and needle to move towards the cell; applying calibration data to detect when the needle has pierced the cell; and reducing the potential further once it has been detected that the needle has pierced the cell. The cell can be a biological cell. The needle can be a micro-needle and the stage can be a micro-stage.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G01N Class
- 0 % this patent is cited more than
- 2 Age
