TEMPERATURE CONTROL DEVICE AND TEMPERATURE CONTROL SYSTEM
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Oct 6, 2022
app pub date -
Sep 29, 2020
filing date -
Sep 29, 2020
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
The embodiment of the present disclosure provides a temperature control device and a temperature control system. The temperature control device comprises an object stage, a housing, and at least one temperature control structure. The temperature control structure has a main body portion and a temperature control component, and main body portion defines an air duct, and wherein, the main body portion has a second air inlet and a second air outlet, and the first air inlet is connected to the second air outlet, and the external air enters the air duct defined by the main body portion from the second air inlet of the main body portion, and the air then enters the housing through the second air outlet, and the temperature control component is connected, so as to the main body portion to control the temperature of the air in the air duct.
First Claim
Other Claims data not available
