Mast safety system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Dec 26, 2023
Grant Date -
Nov 11, 2021
app pub date -
May 5, 2020
filing date -
May 5, 2020
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
A spool may include a drum rotatably supported on an axle shaft and flanges integrally formed with opposite ends of the drum. The drum has a continuous groove on the outer surface of the drum to guide the movement of the safety wireline. Both of the flanges may include an opening, internal threads circumscribing the opening, and a plurality of mechanical brakes. Each of the mechanical brakes may include a rotor rotatably supported on the axle shaft of the spool and a pawl arranged within the opening. The pawl is pivotally linked to the rotor such that when the rotation of the axle shaft is in a direction and at a rotation speed that exceeds a threshold then the pawl is moved by centrifugal force and engages with the internal threads circumscribing the opening and does not permit the spool to rotate.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
- 2020 Application Filing Year
- B66D Class
- 155 Applications Filed
- 102 Patents Issued To-Date
- 65.81 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B66D Class
- 0 % this patent is cited more than
- 2 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Jun 26, 2027 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jun 26, 2031 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jun 26, 2035 |
