Self-locking clamp
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Mar 11, 2021
app pub date -
Sep 4, 2020
filing date -
Sep 6, 2019
priority date (Note) -
Published
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
Self-locking clamp having two clamping jaws (307), a shank (11) connected to clamping jaws (307), and a central part (201). Each jaw (307) is fastened in an articulated manner to the central part (201) via a first flexible connection (9), and the shank (11) has two parts (12, 13) that are connected in an articulated manner to one another at adjacent ends via a second flexible connection (14). The shank (11) is fastened in an articulated manner via a third flexible connection (15) to the one clamping jaw (307) and is fastened in an articulated manner via a fourth flexible connection (17) to the central part (201). The central part (201) is formed such that the shank (11) can assume a snapped-over position adjacent the central part (201) forming a first lock for the shank (11). The clamp also has a second lock (40) holding the shank (11) when snapped-over.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date |
|---|---|---|---|
| SE | A1 | SE2030276 | Sep 04, 2020 |
International Classification(s)
- 2020 Application Filing Year
- B25B Class
- 771 Applications Filed
- 521 Patents Issued To-Date
- 67.58 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B25B Class
- 0 % this patent is cited more than
- 4 Age
