MULTIPLEXER
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Dec 31, 2020
app pub date -
Sep 15, 2020
filing date -
Jun 6, 2018
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A multiplexer includes: a switch capable of connecting a common terminal to at least one of a first selection terminal, a second selection terminal, and a third selection terminal at the same time; a first filter connected to the first selection terminal, the first filter having a first pass band; a second filter connected to the second selection terminal, the second filter having a second pass band that is different from the first pass band; and a coupling circuit connected to the third selection terminal and the first filter, the coupling circuit forming a signal path between the third selection terminal and the first filter by electromagnetic coupling.
First Claim
Other Claims data not available
