CONVEYOR DEVICE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jun 18, 2020
app pub date -
Feb 26, 2020
filing date -
Aug 31, 2017
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A conveyor device includes a supporter extending from a first end of a rotation axis to a second end thereof in a helical manner relative to the rotation axis, an encircling member that encircles at least a third portion of the supporter, the third portion being a portion between a first portion on the first end and a second portion on the second end, and at least one guide for a three-dimensional game object to move from the first end to the second end along with rotation of the supporter, the at least one guide extending from the first end to the second end within a gap between the supporter and the encircling member and being configured such that the guide in coordination with the supporter and the encircling member supports the three-dimensional game object when the three-dimensional game object moves from the first end to the second end.
First Claim
Other Claims data not available
