Length measuring device
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 23, 2021
Grant Date -
Oct 10, 2019
app pub date -
Oct 29, 2018
filing date -
Apr 6, 2018
priority date (Note) -
In Force
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
A length measuring device includes a hook (380) to which a ring of the tape tip is hooked and retained, and the hook (380) includes a first hook (380-1) and a second hook (380-2) provided on both sides of an outlet perpendicularly to each other, in which, when the ring at a leading end of the tape tip is hooked with the first hook or the second hook, a surface of the first hook or the second hook is brought into contact with a rectangular inner peripheral surface of the fastening hole (305), such that the tape tip is retained perpendicularly to the first hook or the second hook.
First Claim
Other Claims data not available
Family
Loading Family data...
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- G01B Class
- 52.69 % this patent is cited more than
- 4 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Aug 23, 2028 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Aug 23, 2032 |
