Servo press machine and setting method for servo press machine
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 21, 2021
Grant Date -
Sep 26, 2019
app pub date -
Mar 18, 2019
filing date -
Mar 23, 2018
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A servo press machine includes a display unit that displays a strip-shaped region for setting a motion of a slide and an operation unit that receives an input operation. A range extending from an upper end of the strip-shaped region to a lower end thereof corresponds to a movement range of the slide in a linear movement, and the strip-shaped region is formed of a plurality of slide operation regions that are consecutive in a direction in which the strip-shaped region extends. Each of the slide operation regions can set a speed of the slide in response to the input operation received by the operation unit, and a boundary between adjacent two of slide operation regions can move along the direction in which the strip-shaped region extends in response to the input operation received by the operation unit.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G05B Class
- 0 % this patent is cited more than
- 4 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 3.5 Year Payment | $1600.00 | $800.00 | $400.00 | Mar 21, 2025 |
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Mar 21, 2029 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Mar 21, 2033 |
