Ignition apparatus having a spring for electrically connecting a spark plug
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 2, 2021
Grant Date -
Jul 25, 2019
app pub date -
Apr 2, 2019
filing date -
Oct 5, 2016
priority date (Note) -
In Force
status (Latency Note)
![]() |
A preliminary load of PAIR data current through [] has been loaded. Any more recent PAIR data will be loaded within twenty-four hours. |
PAIR data current through []
A preliminary load of cached data will be loaded soon.
Any more recent PAIR data will be loaded within twenty-four hours.
![]() |
Next PAIR Update Scheduled on [ ] |

Importance

US Family Size
|
Non-US Coverage
|
Abstract
An ignition apparatus for an internal combustion engine includes a spark plug, an ignition coil with a voltage connection, and a spring for electrically connecting the spark plug to the voltage connection. A continuous spring wire in the form of external turns extends from an ignition coil-side end of the spring to a spark plug-side end of the spring. The spring wire at the spark plug-side end continues in the form of internal turns within the external turns in a direction toward the ignition coil-side end.
