Method for capturing dynamic vibrations of a roughness sensor, method for measuring a roughness of a workpiece surface, computer program product and measuring device configured to carry out the methods
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 17, 2020
Grant Date -
Mar 15, 2018
app pub date -
Nov 17, 2017
filing date -
May 20, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A method for capturing dynamic vibrations of a roughness sensor of a roughness measuring apparatus is provided. The movement of the roughness sensor relative to the roughness measuring apparatus and/or relative to a surface of a workpiece is captured by a measuring system in the frequency range below 100 Hz with a data capturing rate of greater than 100 Hz. The captured data of the relative movement are made available for further data processing in and/or stored. Moreover, a method for measuring the roughness of a workpiece surface is provided, in which the method for capturing the dynamic vibrations of a roughness sensor is used. In addition, a computer program product for controlling a roughness sensor of a roughness measuring apparatus in accordance with one of the methods is provided, and a roughness measuring device that is configured to carry out one of the methods.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 2 Citation Count
- G01B Class
- 40.35 % this patent is cited more than
- 5 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | May 17, 2028 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 17, 2032 |
