Anti-Veining Additive for Silica Sand Mold
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Mar 1, 2018
app pub date -
Aug 29, 2016
filing date -
Aug 29, 2016
priority date (Note) -
Published
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
This invention relates generally to a composition for silica sand cores and molds suitable for in the casting of metals. The sand core composition contains a hinder and a uniformly dispersed anti-veining additive. The mixed metal oxides collapse into a visco-plastic state when the foundry mold/core is heated by the molten metal during casting. A change in state of the MMOx from solid to a visco-plastic at the casting high temperatures provides space and lubricity within the foundry shape sufficient to compensate for the thermally-induced physical expansion of the silica grains. Thereby avoiding the mechanical forces which cause cracks and fissures in the mold or core that produce veins and other surface imperfections associated with the high coefficient of thermal expansion of silica sand.
First Claim
Other Claims data not available
