SINTERED R-TM-B MAGNET
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Mar 22, 2016
filing date -
Mar 27, 2015
priority date (Note) -
Published
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
A sintered R-TM-B magnet comprising 24.5-34.5% by mass of R, which is at least one selected from rare earth elements including Y, 0.85-1.15% by mass of B, less than 0.1% by mass of Co, 0.07-0.5% by mass of Ga, and 0-0.4% by mass of Cu, the balance being Fe and inevitable impurities; the amounts (% by mass) of Ga and Cu being in a region of a pentagon defined by a point A (0.5, 0.0), a point B (0.5, 0.4), a point C (0.07, 0.4), a point D (0.07, 0.1) and a point E (0.2, 0.0), on an X-Y plane in which the X-axis represents the amount of Ga, and the Y-axis represents the amount of Cu.
First Claim
Other Claims data not available
