Apparatus and method for switching vibration at panel surface
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 23, 2019
Grant Date -
Jan 25, 2018
app pub date -
Oct 2, 2017
filing date -
Apr 9, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A drive controlling apparatus drives a vibrating element of an electronic device, the electronic device including a display part, a top panel having a manipulation surface, a coordinate detector configured to detect coordinates of a manipulation input. The drive controlling apparatus includes: a storage part configured to store image data for a scrollable image, to be displayed on the display part and including an input field, in association with position data that represents a position of the input field in the image and input data input in the input field; and a drive controlling part configured to drive the vibrating element according to a first pattern when the input field without the deficiency is being displayed on the display part and to drive the vibrating element according to a second pattern when the input field with the deficiency is not being displayed on the display part.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- H04M Class
- 29.75 % this patent is cited more than
- 6 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jan 23, 2027 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jan 23, 2031 |
