CONTAINER FOR CONSUMER ARTICLES WITH A SPACER CONTAINING A CUT-OUT
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jan 25, 2018
app pub date -
Mar 24, 2016
filing date -
Mar 27, 2015
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
The present invention relates to a container (10) for consumer articles, the container (10) comprising a box portion wherein the box portion comprises a box front wall (14), a box rear wall (16), a box bottom wall and two box side walls (12) extending between the box front wall (14) and the box rear wall (16), and a spacer (20), wherein the spacer (20) is mounted within the box portion, the spacer (20) is mounted essentially perpendicular to the box bottom wall, the spacer (20) is partially projecting out at the upper end of the box front wall (14), and the spacer (20) comprises at least one spacer wall (26, 28, 30), the at least one spacer wall (26, 28, 30) has at least one spacer cut-out (32, 34, 36), and the at least one spacer cut-out (32, 34, 36) is located at the upper end of the at least one spacer wall (26, 28, 30). The container (10), further comprising an inner frame with an inner frame cut-out, wherein the inner frame is provided at the inner side of the box front wall (14) and is partially projecting out at the upper end of the box front wall (14). The present invention further relates to a method of preparing the container (10).
First Claim
Other Claims data not available
