Drive control system for vehicle
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jun 4, 2019
Grant Date -
Jan 18, 2018
app pub date -
Jun 30, 2017
filing date -
Jul 15, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
In a drive control system for a vehicle configured to cause the vehicle to travel in a limp-home mode when a malfunction occurs in a selectable one-way clutch, when it is determined that a malfunction occurs in the SOWC, the cause of the malfunction is specified as one of a plate-open failure of a selector plate that is unintentionally placed in an open state, and a sensor failure. In the case of the plate-open failure, a first limp-home traveling mode is carried out in which the vehicle travels in the limp-home mode while keeping the SOWC in a negative rotational speed range. In the case of the sensor failure, a second limp-home traveling mode is carried out in which the vehicle travels in the limp-home mode while the SOWC is placed in the non-engaged state.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date |
|---|---|---|---|
| JP | B2 | JP6421791 | Jul 15, 2016 |
| CN | B | CN107618353 | Jul 11, 2017 |
International Classification(s)
- 2017 Application Filing Year
- B60K Class
- 3042 Applications Filed
- 2326 Patents Issued To-Date
- 76.47 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- B60K Class
- 24.97 % this patent is cited more than
- 6 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Dec 4, 2026 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Dec 4, 2030 |
