Carbon material, method for producing same, and use for same
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 13, 2019
Grant Date -
Jan 11, 2018
app pub date -
Feb 8, 2016
filing date -
Feb 9, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A non-flaky carbon material having specific optical structures, wherein the ratio between the peak intensity I110 of (110) plane and the peak intensity I004 of (004) plane of a graphite crystal determined by the powder XRD measurement, I110/I004, is 0.10 or more and 0.35 or less; an average circularity is 0.80 or more and 0.95 or less; d002 is 0.337 nm or less; and the total pore volume of pores having a diameter of 0.4 μm or less measured by the nitrogen gas adsorption method is 25.0 μl/g or more and 40.0 μl/g or less. Also disclosed is a method for producing the carbon material, a carbon material for a battery electrode, a paste for an electrode incorporating the carbon material for a battery electrode, an electrode for a lithium battery incorporating a formed body of the paste for an electrode, a lithium-ion secondary battery including the electrode and a method for producing the electrode.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- C01B Class
- 1845 Applications Filed
- 1265 Patents Issued To-Date
- 68.57 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- C01B Class
- 0 % this patent is cited more than
- 6 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 13, 2027 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 13, 2031 |
