Adjustable ECG sensor and related method
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 23, 2019
Grant Date -
Jan 11, 2018
app pub date -
Jul 8, 2016
filing date -
Jul 8, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An adjustable ECG sensor is attachable to a patient to sense cardiac signals and includes an adjustable leadwire having a flexible substrate, a conductor extending along the flexible substrate, and a connector end connectable to a receiver associated with an ECG monitor. The adjustable ECG sensor further includes an electrode having an electrode pad, a clip connected to the electrode pad and attachable to any one of multiple locations on the adjustable leadwire, and a pin that punctures the flexible substrate and electrically connects to the conductor of the adjustable leadwire. The adjustable ECG sensor is fitted to the patient by attaching the clip of the electrode to one of the multiple locations on the adjustable leadwire.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- A61B Class
- 18399 Applications Filed
- 13681 Patents Issued To-Date
- 74.36 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- A61B Class
- 0 % this patent is cited more than
- 6 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jan 23, 2027 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jan 23, 2031 |
