SUBSEA FLUID PROCESSING SYSTEM
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jan 4, 2018
app pub date -
Dec 29, 2015
filing date -
Dec 29, 2014
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A subsea fluid processing system which receives a wellstream flow. The subsea fluid processing system includes a pressure control device which regulates a pressure of the wellstream flow, a gas-liquid separator unit which receives the wellstream flow downstream of the pressure control device and which provides a liquid stream and a gas stream, a first membrane separator which receives the gas stream and which provides a retentate stream and a permeate stream, a compressor which receives the permeate stream and which provides a compressed permeate stream, and a discharge cooler which receives the compressed permeate stream and which provides a cooled compressed permeate stream for injection into a subsurface reservoir. A density of the cooled compressed permeate stream is higher than a density of the compressed permeate stream.
First Claim
Other Claims data not available
