INTERFERENCE REJECTION MEMBRANES COMPRISING CROSSLINKED POLY(VINYL ALCOHOL) MATRICES FOR IMPLANTABLE GLUCOSE SENSORS
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Apr 27, 2016
filing date -
Apr 27, 2016
priority date (Note) -
Published
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
Embodiments of the invention provide amperometric analyte sensors having optimized elements such as interference rejection membranes as well as methods for making and using such sensors. The amperometric analyte sensor apparatus comprises: a base layer; a conductive layer disposed on the base layer and comprising a working electrode; an interference rejection membrane disposed on an electroactive surface of the working electrode, wherein the interference rejection membrane comprises poly(vinyl alcohol) (PVA) polymers crosslinked by an acid crosslinker, wherein the crosslinker is a dicarboxylic acid type monomer or a polymer comprising a carboxylic acid group; and an analyte sensing layer. While embodiments of the innovation can be used in a variety of contexts, typical embodiments of the invention include glucose sensors used in the management of diabetes.
First Claim
Other Claims data not available
