Enabling secure network mobile device communications
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 6, 2018
Issued Date -
N/A
app pub date -
Feb 8, 2017
filing date -
Jan 31, 2005
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
Methods and systems of communicating with secure endpoints included within a secured network from a mobile device external to the secured network is disclosed. The method includes initiating a VPN-based secure connection to a VPN appliance, and initializing a stealth-based service on the mobile device. The method further includes transmitting user credential information from the mobile device to a VDR broker via the VPN appliance, and receiving status information from the VDR broker identifying a VDR associated with the mobile device and providing a connected status. The method also includes communicating with one or more secure endpoints within the secured network via a VPN connection to the VDR via the VPN appliance and through the VDR to the one or more secure endpoints within a community of interest based on the user credential information transmitted to the VDR broker.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2017 Application Filing Year
- H04L Class
- 36365 Applications Filed
- 27259 Patents Issued To-Date
- 74.96 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H04L Class
- 0 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Sep 6, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Sep 6, 2029 |
