Electron-Emitter Transformer and High Voltage Multiplier
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jan 12, 2017
app pub date -
Apr 26, 2016
filing date -
Jul 10, 2015
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
The invention includes a power supply 17 for an x-ray tube 49. The power supply 17 can comprise a control box 48 and a remote box 47. An electron-emitter transformer 14 can be located in the remote box 47. A box-connector cable 41 between the control box 48 and the remote box 47 can be relatively long and an x-ray tube cable 21 between the remote box 47 and an electron emitter 19 can be relatively short. This design can provide improved electrical power transfer from the power supply 17 to the x-ray tube 49. Also, electrical cable size and cost can be reduced if a high voltage source 15 is located in the remote box 47.
First Claim
Other Claims data not available
