OVERCOAT FORMULATION FOR LONG-LIFE ELECTROPHOTOGRAPHIC PHOTOCONDUCTORS AND METHOD FOR MAKING THE SAME
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Aug 23, 2016
filing date -
Mar 15, 2013
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
An overcoat layer and method to make an overcoated photoconductor drum of an electrophotographic image forming device using irradiation such as with electron beam (EB) or ultraviolet (UV) light is provided. The photoconductor drum is then cured using EB dose of between 10 and 100 kiloGrays (kGy), preferably between 20 and 40 kGys or UV irradiation with an exposure of between 0.1 and 2 J/cm2. The unique overcoat layer of the present invention is formed having a biphasic morphology comprised of a highly cured crosslinked phase and a second phase enriched in uncured material. The desired amount of uncured uncrosslinked material found in the second phase of the biphasic structure, is between 2-70 wt % range, with particularly good combination of long-life and electrical performance when present at the 5-50 wt % level, and the best performance at the 15-40 wt % level. The biphasic morphology of the overcoat layer using the method of the present invention gives rise to the good wear rates while allowing rapid transport of the electrical charge and thus fast discharge properties of the photoconductor drum.
First Claim
Other Claims data not available
