SYSTEM AND METHOD FOR DYNAMIC SWITCHING OF ANTENNAS
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Oct 20, 2016
app pub date -
Apr 14, 2015
filing date -
Apr 14, 2015
priority date (Note) -
Published
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
Systems and methods are disclosed for dynamic switching of antennas. A portable information handling system includes a housing having a plurality of edges, a first antenna and a second antenna. The first antenna is located proximate a first edge of the plurality of edges, the second antenna is located proximate a second edge of the plurality of edges. The system includes a switch communicatively coupled to the first antenna and the second antenna, and a processing resource communicatively coupled to the switch. The processing resource is configured to determine a first orientation of the portable information handling system; based on the first orientation, designate the first antenna as a primary antenna and designate the second antenna as a secondary antenna; and direct the switch to transition the primary antenna to an active state and direct the switch to transition the secondary antenna to an inactive state.
First Claim
Other Claims data not available
