PRESSURE SENSOR MODULE AND METHOD FOR MANUFACTURING THE SAME
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jul 21, 2016
app pub date -
Jan 4, 2016
filing date -
Jan 4, 2016
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A pressure sensor module capable of fixing a diaphragm to a base body without using welding is provided. A base body, a first diaphragm, a first elastic body, and a first mounting member are included. The base body has a first recess with a pressure sensor element to be installed inside, and a first receiving surface section extending outward from an opening edge of the first recess. The first diaphragm is provided facing the first receiving surface section so as to close the first recess from an inlet side and arranged separably from the base body. The first elastic body is arranged on one surface side of the first diaphragm outside the opening edge of the first recess. The first mounting member is mounted on the base body with the first diaphragm and the first elastic body pressed toward the first receiving surface section.
First Claim
Other Claims data not available
