Biochip for measuring blood glucose levels, and blood glucose meter for smartphone, containing same
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 4, 2020
Grant Date -
May 12, 2016
app pub date -
Jul 8, 2013
filing date -
Jul 8, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
Disclosed are a biochip for measuring blood glucose levels and a blood glucose meter for a smartphone including the same. The biochip for measuring blood glucose levels includes: a substrate, one surface of which is provided with a blood glucose inflow region into which blood glucose flows and with a reaction region that is connected to the blood glucose inflow region and has a recess formed therein, a porous separator disposed on the blood glucose inflow region to face the surface of the substrate, and silica nanoparticles and a reaction reagent distributed on the reaction region of the substrate. Thereby, blood glucose levels can be measured using such a biochip, which is easy to carry, together with a CMOS image sensor, and particularly, blood glucose levels can be simply measured using a CMOS image sensor provided to a smartphone, and blood glucose levels can be quantitatively measured and checked using a blood glucose meter application installed on a smartphone.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date |
|---|---|---|---|
| CN | B | CN105611874 | Jul 08, 2013 |
| WO | A1 | WO2015005504 | Jul 08, 2013 |
International Classification(s)
- 2013 Application Filing Year
- G01N Class
- 9056 Applications Filed
- 7640 Patents Issued To-Date
- 84.37 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G01N Class
- 0 % this patent is cited more than
- 5 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 4, 2028 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 4, 2032 |
