ELECTRONIC COMPONENT AND MANUFACTURING METHOD THEREOF
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Jun 30, 2015
filing date -
Jul 2, 2014
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
To provide an electronic component having a protective film formed with a good uniformity, over the entire surface thereof. An aspect of the present invention is an electronic component having a protective film formed over the entire surface thereof, the electronic component has elements and wirings formed on a base body, and the protective film has been formed by a CVD method, over an entire surface of said electronic component, by: arranging an electrode in a chamber; grounding one side of the chamber and the electrode; accommodating the electronic component in the chamber; supplying an raw material gas to the chamber; rotating or swinging the chamber and thereby moving the electronic component in the chamber; supplying high-frequency power to the other side of the chamber and the electrode; and generating a raw-material-gas-based plasma between the electrode and the chamber.
