ENDOSCOPES
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Oct 8, 2015
app pub date -
Dec 11, 2013
filing date -
Dec 11, 2012
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
In various embodiments of the present disclosure, there is provided an endoscope including: an elongate shaft body; an optical scope provided within the elongate shaft body, the optical scope comprising an optical aperture provided at the distal end of the optical scope, corresponding to a distal end of the elongate shaft body; an aperture cover provided at the distal end of the elongate shaft body for shielding the optical aperture from debris external to the elongate shaft body; and an actuation system provided at a proximal end of the elongate shaft body; wherein the actuation system drives the aperture cover to rotate.
First Claim
Other Claims data not available
