FILM LAMINATED STRUCTURE, METHOD FOR PRODUCING THE SAME, AND GAS SENSOR
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Oct 1, 2015
app pub date -
Mar 25, 2015
filing date -
Mar 28, 2014
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A method of the present invention is a method for producing a film laminated structure, including the steps of: (a) preparing a substrate; (b) achieving a state that a mold is charged with a slurry that contains a raw material powder, a gelling agent containing at least two polymerizable organic compounds, and an organic solvent serving as a dispersion medium, and that the substrate is placed at a predetermined position in the mold; (c) molding and hardening the slurry through a polymerization reaction of the gelling agent to combine the substrate and a green film to form a green structure; and (d) firing the green structure to form a film laminated structure, the film laminated structure including a porous film formed from the green film by firing.
First Claim
