Lifting apparatus for vehicle wheels
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 8, 2017
Issued Date -
N/A
app pub date -
Mar 30, 2015
filing date -
Apr 1, 2014
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A lifting apparatus for a vehicle wheel comprising a wheel support which is selectively movable in order to lift or lower a vehicle wheel which is positioned thereon. An actuator group is connected to the wheel support in order to actuate the lifting and lowering thereof. A control unit is operationally connected to the actuator group in order to control the actuation. A lifting sensor member is provided to detect the height of the wheel support. At least one actuation instruction brings about the actuation of the actuator group in order to lift the wheel support from a lowered rest position to a predetermined lifting position, which is detected by the lifting sensor member.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2015 Application Filing Year
- G01M Class
- 1327 Applications Filed
- 1023 Patents Issued To-Date
- 77.10 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G01M Class
- 0 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 8, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 8, 2029 |
