PREDICTING LED PARAMETERS FROM ELECTROLUMINESCENT SEMICONDUCTOR WAFER TESTING
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Sep 17, 2015
app pub date -
Jun 1, 2015
filing date -
Aug 21, 2011
priority date (Note) -
Published
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
A diode model and conductive-probe measurements taken at the wafer lever are used to predict the characterization parameters of a semiconductor device manufactured from the wafer. A current-voltage curve (I-V) model that expresses a current-voltage relationship as a function of resistance, ideality factor, and reverse saturation current is fitted to a number of conductive-probe measurement data. The current-voltage curve (I-Vd) for the device is then estimated by subtracting from the (I-V) model the product of current times the resistance produced by fitting the (I-V) model.
First Claim
Other Claims data not available
