ALIGNMENT DEVICE FOR A TURBOMACHINE COMPONENT AND TURBOMACHINE INCLUDING SUCH A DEVICE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 27, 2015
app pub date -
Sep 6, 2013
filing date -
Sep 11, 2012
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A turbomachine includes a component fixedly constrainable to a baseplate of said turbomachine and an alignment device for regulating the position of the component with respect to the baseplate, wherein the alignment device includes at least a first bolt a second bolt and a third bolt, each bolt including a regulating screw respectively coupled with a threaded through hole in the component, each threaded hole defining a respective alignment axis for said component, each screw having a respective axial end which is susceptible of contacting said baseplate for defining the position of the component along each axis, each bolt including a blocking nut for blocking said regulating screws; the alignment device further includes a fourth fixing screw which is screwable in a threaded hole of the baseplate for fixing said component to the baseplate.
