SYSTEM AND METHOD FOR DELIVERING MODULATED SUB THRESHOLD THERAPY TO A PATIENT
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jun 18, 2015
app pub date -
Dec 16, 2014
filing date -
Dec 17, 2013
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A neuromodulation system configured for providing sub-threshold neuromodulation therapy to a patient. The neuromodulation system comprises a plurality of electrical terminals configured for being respectively coupled to a plurality of electrodes, modulation output circuitry configured for delivering modulation energy to the electrical terminals, a user interface for receiving input from a user, and control/processing circuitry configured for generating a super-threshold modulation program based on the received user-input, controlling the modulation output circuitry to deliver super-threshold modulation energy in accordance with the super-threshold modulation program, automatically deriving a plurality of different sub-threshold modulation programs from the super-threshold modulation program, and controlling the modulation output circuitry to deliver sub-threshold modulation energy to a patient in accordance with at least one of the sub-threshold modulation programs.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 33 Citation Count
- A61N Class
- 80.33 % this patent is cited more than
- 10 Age
