SOUNDER MODULE AND METHOD FOR ASSEMBLING THE SAME
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Feb 5, 2015
app pub date -
Oct 12, 2012
filing date -
Feb 22, 2012
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A sounder module, comprising a sounder unit and a casing housing the sounder unit; the sounder unit comprises a magnetic circuit system; the magnetic circuit system comprises a concentrating flux, plate, a magnet and a magnet yoke (33) sequentially assembled; moreover, the casing of the sounder module forms a frame for fixing the magnetic circuit system of the sounder; and the magnetic circuit system and the casing are injection molded to form an integrated structure Also provided is a method for assembling the casing and the magnetic circuit system: a) firstly, sequentially assembling the concentrating flux plate, the magnet and the magnet yoke (33); b) placing the assembled concentrating flux plate, the magnet and the magnet yoke in an injection molder forming the casing; and c) adding molding material, and integrating the magnetic circuit system with the casing.
