METHOD OF MANUFACTURING A MULTI-LAYER GOLF BALL
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jan 8, 2015
app pub date -
Jul 5, 2013
filing date -
Jul 5, 2013
priority date (Note) -
Abandoned
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
A method of manufacturing a multi-layer golf ball includes injection molding a core from an ionomeric thermoplastic material such that the core has an outer surface that includes a plurality of protrusions extending radially outward from a spherical land portion, with each protrusion having a maximum height relative to the spherical land portion of between 0.15 mm and 2.0 mm. The core is then positioned between a first hemispherical shell and a diametrically opposed second hemispherical shell, which are each formed from a rubber material. The first and second hemispherical shells are then compression molded such that rubber material conforms to the outer surface of the core. The rubber material is then cured to form a unitary intermediate layer that surrounds the core. Finally, a cover layer is molded about the intermediate layer through one of injection molding and compression molding.
First Claim
Other Claims data not available
