ORGANIC ELECTROLUMINESCENT DEVICE AND METHOD FOR PRODUCING SAME
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Sep 2, 2014
filing date -
Mar 15, 2012
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
The present invention attempts to improve coating processes used to produce organic EL devices, such as that an under layer is dissolved by a coating solution and efficiency and stability are poor. The present invention provides an organic EL device equipped with at least a first electrode formed on a substrate, a light emission medium layer containing at least an organic light emission layer, and a second electrode so formed as to face the first electrode so that the light emission medium layer can be sandwiched between the first electrode and the second electrode, wherein at least the organic light emission layer and a hole-transport layer adjacent to the organic light emission layer are contained in the light emission medium layer, and at least a low-molecular-weight hole-transport material and a matrix polymer having insulation properties and weight average molecular weight of about 200,000 to about 50,000,000 inclusive are contained in the hole-transport layer.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H01L Class
- 0 % this patent is cited more than
- 11 Age
