Method for detecting presence of a droplet on a heated temperature sensor
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Nov 27, 2014
app pub date -
Nov 22, 2012
filing date -
Dec 22, 2011
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A method for detecting the presence of a droplet on a heated temperature sensor, especially on a heated temperature sensor of a thermal, flow measuring device for measuring flow of a fluid. The method steps are as follows: ascertaining the greatest value of a measure for heat transfer from the heated temperature sensor to the fluid in a first time window of predetermined length; testing values of the measure for heat transfer in the first time window for the presence of values of the measure for heat transfer before and after the greatest value of the measure for heat transfer, which are less than the difference between the greatest value and a predetermined Δ1; and applying the results of the testing for detecting the presence of a droplet.
