System and Method for Using a Pulse Flow Circulation for Algae Cultivation
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
May 6, 2014
filing date -
Jul 25, 2011
priority date (Note) -
Published
status (Latency Note)
Importance
Abstract
A device for generating a pulsed flow in a channel containing a circulating algal culture can include a plate that is pivotably mounted on the channel and an activator. A pulsed flow is generated in the channel by first positioning the plate to impede the flow of circulating algal culture and then rotating the plate to a submerged position. The pulsed flow can be employed to counteract the negative effects of bio-fouling on algae cultivation equipment. In another arrangement, a device for generating a pulsed flow in a sloped raceway that is in fluid communication with a sump can include a gate. In different embodiments, the gate can operate as a so-called “pinch gate” or as a so-called “overflow gate.” In another aspect, a variable rate pump, such as a centrifugal pump, a screw pump or an airlift pump, is described for establishing a pulsed flow in a channel.
First Claim
Other Claims data not available
