QUENCHED AND PARTITIONED HIGH-CARBON STEEL WIRE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 14, 2014
app pub date -
Sep 19, 2012
filing date -
Sep 20, 2011
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A high-carbon steel wire has as steel composition: a carbon content ranging from 0.40 weight percent to 0.85 weight percent, a silicon content ranging from 1.0 weight percent to 2.0 weight percent, a manganese content ranging from 0.40 weight percent to 1.0 weight percent, and a chromium content ranging from 0.0 weight percent to 1.0 weight percent. The remainder is iron. This steel wire has as metallurgical structure a volume percentage of retained austenite ranging from 4 percent to 20 percent, while the remainder is tempered primary martensite and untempered secondary martensite. The steel wire is obtained by partitioning after quenching.
First Claim
Other Claims data not available
