Abstract

Internet routers are a key component in today's Internet. Each router forwards received packets toward their final destinations based upon a Longest Prefix Matching (LPM) algorithm select an entry from a routing table that determines the closest location to the final packet destination among several candidates. Prior art solutions to LPM lookup offer different tradeoffs and that it would be beneficial for a design methodology that provides for low power large scale IP lookup engines addressing the limitations within the prior art. According to embodiments of the invention a low-power large-scale IP lookup engine may be implemented exploiting clustered neural networks (CNNs). In addition to reduced power consumption embodiments of the invention provide reduced transistor count providing for reduced semiconductor die footprints and hence reduced die cost.

First Claim
