PLASMA ACTIVATED DEPOSITION OF A CONFORMAL FILM ON A SUBSTRATE SURFACE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Jul 31, 2014
app pub date -
Apr 2, 2014
filing date -
Feb 14, 2012
priority date (Note) -
Published
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
An apparatus deposits a film on a substrate including a reaction chamber arranged on a substrate support. An inlet port delivers gas phase reactants to the reaction chamber. A plasma generator provides plasma to the reaction chamber. A controller is configured to flow a silicon-containing reactant from a precursor group consisting of di-tert-butyl diazidosilane, tris(dimethylamido)silylazide, and bis(tert-butylhydrazido)diethyl silane. The silicon-containing reactant is introduced in vapor phase into the reaction chamber. The controller flows a second reactant in vapor phase into the reaction chamber.
First Claim
Other Claims data not available
