METHOD AND DEVICE USING PHOTOELECTRONS FOR IN-SITU BEAM POWER AND STABILITY MONITORING IN EUV SYSTEMS
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Dec 9, 2013
filing date -
Dec 12, 2012
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
The invention presented is a real time EUV illumination metrology device that includes at least one pair of electrodes mounted on an insulator substrate with an aperture defined by the at least one pair of electrodes and/or the insulator substrate. The electrodes of each of the pairs of electrodes are separated by an arc suppression distance. In one alternate embodiment, the metrology device includes four pairs of electrodes. The device may also include a voltage biasing component to divert unwanted electrons that may distort illumination measurement. Also presented is an EUV illumination system incorporating the metrology device. One object of the invention is to provide a system of real time measurement of an EUV illumination beam.
First Claim
Other Claims data not available
