SUN TRACKING LIGHT DISTRIBUTOR SYSTEM HAVING A V-SHAPED LIGHT DISTRIBUTION CHANNEL
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Dec 5, 2013
app pub date -
Feb 28, 2013
filing date -
Jun 5, 2012
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A sun-tracking light distributor system for use in one of an open-ended system and a closed photo-bioreactor for a photosynthetic culture having an aqueous liquid. The sun-tracking light distributor system comprises two light distribution walls, provided at an angle and oriented to converge at a bottom end, the light distribution walls being made of a transparent material allowing sunlight to pass therethrough, the two converging light distribution walls creating an elongated V-shaped channel with an interior space adapted to receive the sunlight and an exterior surface adapted to be partly immersed in the aqueous liquid in use; and a displacement system operatively connected to at least one of the two light distribution walls, the displacement system being adapted to change an orientation of at least one of the two light distribution walls to track a solar position with respect to at least one axis.
First Claim
Other Claims data not available
