ULTRASOUND PROBE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
N/A
app pub date -
Jun 1, 2012
filing date -
Jun 7, 2011
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
An ultrasound probe includes a receiving section to receive ultrasound waves from an object and to acquire a receiving signal of each of multiple channels; a beam forming section to adjust a phase of the receiving signal of each of multiple channels and to sum the receiving signals; an image producing section to produce image data to display an ultrasound diagnostic image based on the receiving signals summed by the beam forming section; a transmission target selecting section to select one from at least two of the receiving signal for each of multiple channels, the receiving signals summed by the beam forming section, and the image data as a transmission target; and a transmitting section to transmit the transmission target selected by the transmission target selecting section.
First Claim
Other Claims data not available
