METHOD FOR MANUFACTURING MULTI-DISPLAY DEVICE
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
N/A
Issued Date -
Aug 16, 2012
app pub date -
Aug 16, 2010
filing date -
Aug 14, 2009
priority date (Note) -
Abandoned
status (Latency Note)
Importance
Abstract
A method for manufacturing a multi-display device by arranging adjacently a plurality of liquid crystal display panels includes: cutting the liquid crystal display panels along at least one edge to remove portions of the liquid crystal display panels respectively; arranging and fixing the liquid crystal display panels, in a state that a portion of the liquid crystal display panels is turned over, such that the cut edges face one another; removing a polarizer attached to a side of the liquid crystal display panel which will be turned over; and attaching a polarizer, which is of the same kind as a polarizer originally attached to the opposite side, to the side of the liquid crystal display panel from which the polarizer has been removed.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 3 Citation Count
- B23P Class
- 12.40 % this patent is cited more than
- 13 Age
